ELECTRICAL/OPTICAL
Voltage：AC100-240V50/60Hz
Light source：18PCSx 40W RGBW 4 IN 1 Orsam LEDs
LED strips：LED 5050RGB 83 pcs 0.12W
Laser：8W RGB Animation laser
Color temperature：2500-8000k linear dimming
Rated lifetime：50000 Hours
Zoom angle：4-60°
COLOR
Limitless color mixing,color macro function
DYNAMIC EFFECTS
Pan/tilt: 540°/270°, 16-bit control and automatic return correction
Operating Mode：Wash、Beam、FX(kaleido effects）
Strip effect：Strobe、Horse racing、Built -in program.
Dimming：0-100% linear electronic dimming
Strobe：Adjustable speed stop/strobe effect,with instantaneous blackout
Front lens： Bi-directional limitless rotation,seamless splicing Len aspherical lens structure
CONTROL/PROGRAMMING
Channel：52/76/148CH
Display：LCD touch display screen
Software：Update software by DMX
Control mode：DMX512、Sound active、Auto run、Master Slave、Bulit-in program
OTHERS
IP rating：IP20
Net weight：22.4KG
Gross weight：26.65KG
Packing size：66x54x41CM
POWER SUPPLIES:100-240V 50/60Hz
LAMP SOURCE:18×40W RGBW Osram LEDs,50,000 h
LED Strips: 5050RGB 83PCS*0.12W
Laser power: 10W RGB laser
Color temperature:2500 - 8000K
OPTICS:4°-60° Electronic Zoom angle
Three operating modes: wash, beam, FX (Kaleido effects)
Front Lens Bi-directional Rotation
Digital Wash-Beam Framing effect
Beam edge softening control (in Wash mode)
0-100% linear electronic dimmer
Carton laser effect
Adjustable speed stop/strobe effect, with instantaneous blackout
Dedicated channel for color temperature setting
RGBW auto-tuning,CONTROL AND PROGRAMMING
DMX512: 3/5-pin XLR IN-OUT sockets
Power connect: Powercon in&out
Display:LCD display
Travel:PAN = 540°,TILT = 210°
Channel:52/76/148CH
Packing size:645x535x415mm
Net weight: 22KG
Gross weight:26 Kg
