ELECTRICAL/OPTICAL
Voltage：AC100-240V50/60Hz
Light source：19pcs 60/40W RGBW 4 IN 1 lamp
LED strips：LED 5050RGB 83 pcs 0.12W
Color temperature：2500-8000k linear dimming
Rated lifetime：50000 Hours
Zoom angle：4-60°
COLOR
RGB Limitless color mixing,with color macro function
DYNAMIC EFFECTS
Pan/tilt: 540°/270°, 16-bit control and automatic return correction
Operating Mode：Wash、Beam、FX(kaleido effects）
Strip effect：Strobe、Horse racing、Built -in program.
Dimming：0-100% linear electronic dimming
Strobe：Adjustable speed stop/strobe effect,with instantaneous blackout
Front lens： Bi-directional limitless rotation,seamless splicing Len
aspherical lens structure
CONTROL/PROGRAMMING
Channel：22/79/98CH，25/101CH，36/93/112CH，43/119CH
Display：LCD touch display screen
Software：Update software by DMX
Control mode：DMX512、Sound active、
Auto run、Master-slave、Bulit-in program
OTHERS
IP rating：IP20
Net weight：21KG
Gross weight：25.8KG
Packing size： 66x54x41cm
POWER SUPPLIES:100-240V 50/60Hz
LAMP SOURCE:19×60W RGBW LEDs,50,000 h.
LED Strips: 5050RGB 83PCS*0.12W
Color temperature:2500 - 8000K
4°-60° Electronic Zoom angle
3 operating modes: wash, beam, FX (Kaleido effects)
Front Lens Bi-directional Rotation
Digital Wash-Beam Framing effect
Beam edge softening control (in Wash mode)
0-100% linear electronic dimmer
Adjustable speed stop/strobe effect,
with instantaneous blackout
Dedicated channel for color temperature setting
RGBW auto-tuning, Channel:21/35/78/92/97CH
Automatic repositioning of PAN and TILT after accidental
movement not controlled by control unit.
Display:LCD display, Travel:PAN = 540°,TILT = 210°
Size:645x535x415mm Weight:21 Kg
