ELECTRICAL/OPTICAL
Voltage：AC100-240V50/60Hz
Light source：Osram 420/361W Lamp
Rated lifetime：4500Hours
Beam angle: 1.8 degree
Optic lens: 165mm
GOBO
Static gobo wheel: 17 static gobos + open
COLOR
Color wheel：14 colors+open, with rainbow wheel and rainbow effect
DYNAMIC EFFECTS
Pan/tilt: 540°/270°, automatic return correction
Prism wheel 1：(6+12)facet prism, 6 linear prism
Prism wheel 2: (8+16+24) facet prism
Focus: High-precision glass lenses, electronic linear HD focus
Dimmer: 0-100% linear electronic dimming
Strobe: 0-20Hz, synchronized, pulse effects
Frost angle：Linear frost
CONTROL/PROGRAMMING
Channel：17CH
Display：LCD display
Software： Update software by DMX connection
Control mode: DMX 512,RDM,Auto-running,Master/salve,
Sound active, Built-in program
OTHERS
Net weight：16.3KG
Gross weight：18KG
IP class：IP20
Package size: 40*32.5*67CM
Input Voltage:100-240V 50/60 Hz
Light Source: OSRAM 371W/ 18R Lamp
Gobos：one static gobo wheel: 14 gobos+ open
Color：one color wheel 14 colors+ open
Prism: Prism wheel 1: 6 facet prism ， 16 facet prism,
Prism wheel 2: 32 facet prism， 6 facet linear prism ，(6+12 facet) combined prism
Beam angle： 1.8°
Dimming：0～100% Linear dimming
Strobe：With strobe effect
Frost：With frost effect
Display:LCD display
Channel： 16/19 CH
Control Mode：DMX 512,RDM,Artnet(optional),Auto-running ,
Master/salve, Sound active, Built-in program
Movement：Pan 540°；Tilt 270°；
Auto X/Y repositioning, fast, quiet and smooth
Gross weight: 23KG
Net Weight：21KG
Packing size: 480*460*735MM
