ELECTRICAL/OPTICAL
Voltage：AC100-240V50/60Hz
Light source：280W Lamp
Rated lifetime：1500Hours
Beam angle: 1.8 degree
Optic lens: 152mm
GOBO
Static gobo wheel: 17 static gobos + open
COLOR
Color wheel：14 colors+open, with rainbow wheel and rainbow effect
DYNAMIC EFFECTS
Pan/tilt: 540°/270°, automatic return correction
Prism：2 independent prism wheel , 12 facet prism，(8+16+24) facet prism
Focus: High-precision glass lenses, electronic linear HD focus
Dimmer: 0-100% linear electronic dimming
Strobe: 0-25Hz, synchronized, pulse effects
Frost ：Linear frost
CONTROL/PROGRAMMING
Channel：17CH
Display：LCD display
Software： Update software by DMX connection
Control mode: DMX 512,RDM,Auto-running,Master/salve,
Sound active, Built-in program
OTHERS
IP class：IP20
Net weight：13KG
Gross weight：14KG
Package size: 40*32.5*67CM
Input Voltage: 110-240V,50/60Hz;
Lamp: 280W Lamp
Gobo: one static gobo wheel, 13 gobos +open
Color: one color wheel, 14 colors + white, With half color
one rainbow wheel: 6 colors
Prism : 2 prisms , 12 facet prism,
(8+16+24)facet combined prism, frost function
Beam angle：1.8°
Dimmer : 0-100% electronic adjustment
Strobe: Support mechanical strobe and adjustable speed strobe effect,
support strobe macro function;
Frost: With frost effect
Channel：17CH
Control Mode：DMX 512,Auto-running ,Master/salve,
Sound active, Built-in program
Movement：Pan 540°；Tilt 270°；Auto X/Y repositioning, fast, quiet and smooth
Gross weight: 17KG
Net weight: 15KG
Packing size: 430*350*490MM
