ELECTRICAL/OPTICAL
Voltage：AC100-240V50/60Hz
Light source：Osram 420W Lamp
Rated lifetime：4500Hours
Beam angle: 1.5°
Optic lens: 200mm large optic lens
GOBO
Static gobo wheel: 13 static gobos + open,with dynamic and shake effect
COLOR
Color wheel：14 colors+open, with rainbow wheel and rainbow effect
DYNAMIC EFFECTS
Pan/tilt: 540°/270°, automatic return correction
Prism wheel 1：12 facet prism, 6 linear prism
Prism wheel 2: (8+16+24) facet prism
Focus: High-precision glass lenses, electronic linear HD focus
Dimmer: 0-100% linear electronic dimming
Strobe: 0-20Hz, synchronized, pulse effects
Frost angle：Linear frost
CONTROL/PROGRAMMING
Channel：17CH
Display：LCD display
Software： Update software by DMX connection
Control mode: DMX 512,RDM,Auto-running,Master/salve,
Sound active, Built-in program
OTHERS
IP class：IP65
Net weight：29.9kg
Gross weight：33.1kg
Package size: 81*50*43CM
Input Voltage:100-240V 50/60 Hz
Light Source: Osram 420W Lamp
Gobos：one static gobo wheel:13 + open
Color: one color wheel,14 colors + open
Prism Wheel 1: 12 facet prism, and 6 linear prism, Frost
Prism Wheel 2: (8+16+24) facet prism
Beam angle:1.5°
Optic lens: 200mm large optice lens
Dimming:0-100% Linear dimming
Strobe: With strobe effect
Frost: With frost effect
IP Class: IP65
Display: LCD display
Channle:17 CH
Control Mode：DMX 512,RDM,Artnet(optional),Auto-running ,
Master/salve, Sound active, Built-in program
Movement：Pan 540°；Tilt 270°；
Auto X/Y repositioning, fast, quiet and smooth
Net Weight: 29KG
Flight case package size: 94*46*93CM
